Split Cartridge Seal | RFB95
Split Cartridge Seal | RFB95
Couldn't load pickup availability
Need Help? Call 888-730-2739 or 802-524-7100
Features & Benefits
Features & Benefits
- Only two halves to assemble for simplified installation
- All integral components mounted on a common split sleeve
- Stationary design ensures maximum alignment
- Cartridge style setting clips for easy setup
- Can be assembled outside the stuffing box
- Springs protected by O-ring for extended life
- Positive set screw drive for secure attachment
- Fully pressure tested at the factory for reliability
- Universal gland design for broad compatibility
- Allows impeller adjustments without seal removal
- Available in metric sizes
Standard Materials of Construction
Standard Materials of Construction
- Faces: Carbon vs. Silicon Carbide, Silicon Carbide vs. Silicon Carbide
- Elastomers: Viton, EPR, AFLAS
- Springs: Hastelloy® C276
- Metallurgy: 316 Stainless Steel
Operating Limits
Operating Limits
- Shaft Speed: Up to 5,000 FPM
- Temperature: Up to 350°F (175°C)
- Pressure: Up to 250 PSI (17 BAR)
